M12 capacitive sensor liquid level sensor can be used for induction of metal nonmetal plastic water and oil, etc

Switch lag: 3-15%

Standard tester: Iron 8 x 8 x 1mm

Repeat accuracy: less than 3%

Output leakage current: less than 0.01mA

No load current: less than 10mA

Output current: less than 200mA

Conduction pressure drop:less than 2V

Protection: polarity reverse protection; power pulse suppression protection; load short circuit protection

LED display: action indicator (yellow)

Working temperature (c): - 25 to +70 DEG C

The effect of temperature: less than 10%

The storage temperature (c): - 25 to +80 DEG C

Insulation impedance: above 50M omega (DC 500V megabytes), between the charging unit and the outer shell

EMC: conforms to standard E N 6094 7-5-2

Protection level: IP67

Connection mode: Cable: 2m; diameter of 3.2mm

Material: shell material: Brass nickel plating; surface material: plastic

If you need other parameters, you can send mail to 913443865 @ qq.com
